Product Overview
Product Name
Ultrasonic Metal Wire Harness Welder
Model Number
JHN2080D-W
Key Selling Point
Easy to Operate
Condition
New
Marketing Type
Hot Product 2025
Place of Origin
Guangdong, China
Technical Specifications
Rated Power
8000W
Ultrasonic Frequency
20KHz
Input Voltage
AC 220V, 50Hz
Max. Power Consumption
8000W (Customizable)
Max. Welding Area
Wire Harness welding
Physical Parameters
Net Weight
Approx. 350kg
Gross Weight
Approx. 380kg
Air Cylinder
Built-in cylinder
Head Color
Blue + Silver
Controller Dimensions
109cm(L) × 86cm(W) × 176cm(H)
Core Components
PLC
Application & Support
Applicable Industries
Welding Materials
Usage
Copper/Aluminum wire bundle welding
Machinery Test Report
✅ Provided
Video Inspection
✅ Provided
Showroom Location
None
Key Advantages
High-quality ultrasonic transducer with strong power and stability
Excellent conductivity with near-zero resistivity
Capable of welding oxidized or plated metals
Short welding time, no additional flux/gas/solder required
No welding sparks – environmentally safe operation
Stepless amplitude adjustment reduces component replacement
Low energy consumption, high efficiency, no distortion
Material doesn't melt – maintains metal properties
Suitable for low-oxidation or plated metal surfaces
